Tint Wholesale

IR Nano Ceramic

$155.00
Shipping calculated at checkout.

** 60" x 100' Special

-One Free Cut ( Please indicate how do you want your cut on order notes at Checkout. )

  • VLT 5%, 15%, 20%, 30%, 35%, 40%, 50% & 70%
  • Advance Nano-Ceramic Technology
  • Block out most UV & IR rays for maximum protection
  • IR Rejection up to 80% in wide bandwidth 780nm – 2500nm
  • No Fading / No Color Change / Color Stable
  • Metal / Dye free construction
  • Lifetime Warranty
VLT: 5%
Roll Size: 20" x 100'
VLT: 5%
Roll Size: 20" x 100'

5% 15% 20% 30% 35% 40% 50% 70%
 Visual Light Transmission % 5 14 19 30 34 40 49 76
 Solar Transmission % 12 18.5 23.2 31.3 32 36.9 33.4 45.7
 Solar Absorption % 82.8 76.6 71.8 63.4 62.6 58.0 61.0 48.4
 Solar Reflectance % 5.2 4.9 5.0 5.3 5.4 5.1 5.6 5.9
 VLR % Interior 5.9 5.8 5.9 6.2 6.2 6.0 6.8 8.2
 VLR % Exterior 5.3 5.1 5.2 5.6 5.6 6.8 6.8 8.0
 IR Rejection % (900 - 1000nm) 80 73 68 62 60 56 75 72
 IR Rejection % (780 - 2500nm) 89 84 84 82 81 79 91 89
 UV Rejection % 99 up 99 up
99 up
99 up
99 up
99 up
99 up
99 up
 Shading Coefficient  0.45 0.5 0.53 0.59 0.6 0.64 0.62 0.72
 SHGC 0.36 0.41 0.44 0.48 0.50 0.53 0.54 0.59
 TSER % 64 59 56 52 50 47 46 41
